Boss OD-1X Overdrive Compact Guitar Pedal
Move your mouse over image or click to enlarge
Boss OD-1X Overdrive Compact Guitar Pedal Boss OD-1X Overdrive Compact Guitar Pedal Right Angle Boss OD-1X Overdrive Compact Guitar Pedal Left Angle Boss OD-1X Overdrive Compact Guitar Pedal Top Angle Boss OD-1X Overdrive Compact Guitar Pedal Special Box

Boss OD-1X Overdrive Compact Guitar Pedal

by Boss
OD-1X; taking the Boss overdrive you know and love roaring into the modern era with incredible expression and a peerless level of performanc..

Read More



OD-1X; taking the Boss overdrive you know and love roaring into the modern era with incredible expression and a peerless level of performance.

Special Edition Boss OverDrive

Combining over 40 years of technical knowledge, pedal design innovation and cutting edge technology, this next generation Boss OverDrive pedal delivers a new tonal experience that only Boss could bring you.

Boss X Series Technology

When designing the X Series pedals, Boss wanted to deliver something truly special. To that end, an incredible amount of research and development was put in to creating the proprietary Boss MDP chip, allowing for Multi-Dimensional Processing.

Multi-Dimensional Processing, or “MDP” for short, allows the pedal to analyse your performance and adapt its own output to your playing.

With the OD-1X, you get overdrive unlike any other pedal you may have tried. Try some heavy riffing and the OD-1X gives you flawless, fat tones. Slip into some chord strumming and you’ll get the smoothest transparent grind. Really dig in and it roars.

The MDP technology allows the OD-1X to naturally follow the dynamics of your performance, with the tonal character and amount of overdrive perfectly complementing your playing, giving you an unprecedented degree of subtlety and nuance.

The combined input from the world’s greatest guitarists and the engineers at Boss has produced an incredibly musical, inspiring and exciting technology in the Boss X Series pedals.

Incredible Overdrive Sound

Being a special edition Boss overdrive pedal, the all-new design gives you a much superior playing experience that you just cannot get from an analogue overdrive pedal.

With the real-time processing thanks to the OD-1X’s digital technology you get a rich, and wide tonal range with natural compression while the unique characteristics of your guitar and pickups are beautifully preserved.

Thanks to the painstaking and meticulous work from the good people at BOSS, the OD-1X pedal has extremely low noise levels so you get beautifully clear signal – even when you are at the highest gain settings.

Solid, Intuitive Design

At the top of the pedal you will find four knobs, giving you full control over your sonic output- LEVEL, LOW, HIGH and DRIVE. Thanks to the recessed control panel design that Boss incorporates on their compact guitar pedals there’s no danger of accidentally knocking your settings when you’re rocking out on stage.

The thick chrome control plate is very sturdy and gives the pedal a nice, classy look along with exclusive chrome knobs that haven’t been seen on Boss pedals before.

A silver screw secures the battery compartment, paying tribute to the original Boss stompbox pedals released back in the 1970s.

Also, being Boss guitar pedals, the robust all-metal chassis is nigh on indestructible and is perfect for taking on the road.

Delivering a huge, bold tone with an unprecedented response to your playing, the OD-1X is overdrive like you’ve never experienced before and is essential for the guitarist who holds their tone paramount.

Boss OD-1X OverDrive Guitar Pedal Key Features:

  • BOSS Five-Year Warranty
  • Special Edition BOSS Overdrive Pedal
  • Multi-Dimensional Processing (MDP) with Proprietary Technology
  • Striking Appearance with Exclusive Chrome Knobs and Control Plate
  • Vintage Style Silver Battery Compartment Knob
  • Drive, High and Low Knobs offer Wide Range of Sound Shaping
  • Very Low Noise, Even with High-Gain Settings
  • Preserves Unique Tonal Characteristics of Your Guitar and Pickup Types
  • Bold, High-Definition Tone that is Smooth and Refined
  • Powerful Real-Time Processing Delivers Rich, Wide-Range Sounds with Natural Compression
  • All-New Design Provides Superior Playing Experience Unattainable with Analogue Overdrive Pedals

Boss OD-1X OverDrive Guitar Pedal Key Specs

  • Next-Generation Sound, Feel and Response
  • Boss OD-1X OverDrive Guitar Pedal Specs:
  • Nominal Input Level: -20 dBu
  • Input Impedance: 1 M ohm
  • Nominal Output Level: -20 dBu
  • Output Impedance: 1 k ohm
  • Recommended Load Impedance: 10 k ohms or greater
  • Controls: Pedal switch, LEVEL knob, LOW knob, HIGH knob, DRIVE knob
  • Indicator: CHECK indicator (Serves also as battery check indicator)
  • Connectors: INPUT jack, OUTPUT jack, AC adaptor jack (DC 9 V)
  • Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22), AC adaptor (sold separately)
  • Current Draw: 45 mA
  • Accessories: Owner's Manual. Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information"), Alkaline battery (9V, 6LR61)

Expected Battery Life Under Continuous Use

  • Alkaline: Approx. 9 hours
  • Carbon: Approx. 2.5 hours

* These figures will vary depending on the actual conditions of use.


Weight (kg)2.0000
Power Supplyac/dc 9v adaptor (sold separately), alkaline battery (9v, 6lr61) or carbon-zinc battery (9v, 6f22)
Warranty5 years
