A super-fast digital mixer allowing you to respond accurately and quickly to the music and artists on the stage thanks to its TouchFlow Operation. With 32 channels you have full control over your domain, giving you the breathing space to work your magic.

Easy and Simple Engineering

Whether you're a seasoned pro or a complete novice, the easy TouchFlow Operation interface on the Yamaha TouchFlow TF5 32 Channel Digital Mixer delivers complete simplicity, making achieving the perfect mix easier than ever.

Recallable D-PRE preamplifiers offer accurate audio quality plus the Yamaha TF5 arrives with advanced live recording applications allowing you to record the artist or band on stage.

Yamaha TouchFlow TF5 32 Channel Digital Mixer Key Features:

  • 33 Motor Faders (32 Channels + 1 Master)
  • 48 Input Mixing Channels
  • 8 DCA Groups with Roll-out
  • 32 analog XLR/TRS combo mic/line inputs
  • 1 Expansion Slot for NY64-D Audio Interface Card

TouchFlow Operation

The engineers at Yamaha deliver a workhorse of a digital mixer with easy touch-screen technology offering a seamless operation of the mixer.

With user-friendly presets and scenes, the Yamaha TF5 mixer operation can be dialled in comfortably and effortlessly.

Most applications can be executed via the touch panel which you'll soon get used to with support from physical controls. Whether you're a complete newbie to touch panel mixer controls or an experienced engineer, you'll be working with this mixer with complete confidence in no time.

Touch and Turn Control

Right next to the touch control panel is a physical Touch and Turn knob, which allows extra control and precision over any EQ adjustments.

Not only that, there are four user-defined knobs that can be assigned to such functions as compressor threshold, EQ gain, or any other parameters you need quick and essential access to when you're working the mix.

Compression and EQ Control Knobs

The 1-Knob COMP allows compression control, whether it be a guitar amp, drum snare or vocals, without having to mess around with various parameters to deliver the desired compressor effect.

The 1-Knob EQ allows you to get great EQ results almost instantaneously. Also, featuring a vocal mode to offer full clarity and clean vocal output.

What's more, both of these knobs are available on the output channels, so you can add the compression or EQ to the room you're working in.

Gain Setup with Gainfinder

Gainfinder allows you to offer optimum gain setup for individual input signals delivering ideal operation and signal quality.

For traditionalists, the level meters also perform their standard function, so the gain setup procedure can be followed if preferred.

QuickPro Presets

Featuring a range of shortcuts to that perfect sound by instrument. Novices will find this a fantastic feature, while experienced engineers will find it useful, to get to where they want it quickly adjusting it after.

StageMix and MonitorMix Apps

The Yamaha TF StageMix app lets you use your mixer from anywhere in the room.. The app visually replicates your TouchFlow’s panels and has easy to use controls that act instantly to your mix. Perfect for bands or artists if they're sorting their own mixes while sound checking on stage.

With level and panning controls, the Yamaha MonitorMix is a bespoke app that provides app users with their own monitoring system.

Yamaha TouchFlow TF5 32 Channel Digital Mixer Features:

  • TouchFlow Operation
  • 1-knob COMP and 1-knob EQ
  • GainFinder
  • QuickPro Presets
  • Two Scene Memory Banks
  • Comprehensive Fader Bank
  • DCA Roll-Out Enhanced Group Control
  • Channel Name and Colour
  • Faders Provide a Clear View of All Inputs
  • TF Editor Facilitates Offline Editing Plus Showtime Control
  • TF StageMix for Wireless Mixing via iPad
  • Personal Monitoring via MonitorMix
  • Recallable D-PRE Microphone Preamplifiers
  • Powerful Processors and Effects

Yamaha TouchFlow TF5 32 Channel Digital Mixer Specs:

  • Fader Configuration: 32 + 1 (Master)

Mixing Capacity

  • Input Channels: 48 (40 Mono + 2 Stereo + 2 Return)
  • Aux Buses: 20 (8 Mono + 6 Stereo)
  • Stereo Buses: 1
  • Sub Buses: 1
  • Input Channel Functions: 8 DCA Groups


  • Inputs: 32 Mic/Line (XLR/TRS Combo) + 2 Stereo Line (RCA pin)
  • Outputs: 16 XLR
  • Expansion SlotS: 1

On-Board Processors

  • DSP: 8 Effects + 10 GEQ
  • USB: 34 x 34 USB Audio Interface, 2 Track Recording via USB Storage Device
  • Power Requirements: 100-240V 50/60 Hz
  • Power Consumption: 120 Watts
  • Dimensions: 866mm x 225mm x 599mm (W x H x D)
  • Net Weight: 20 kg
  • Operating Temperature: 0 - 40 °C
  • Storage Temperature: -20 - 60 °C

Optional Extras (Not Included)

  • Expansion Card
  • Foot Switch FC5
More Information
Manufacturer Yamaha
SKU 138790
Shipping Weight (kg) 20.000000
Channels 32 channels
Warranty 2 Years
Series TF Series
