Line 6 Helix HX Stomp Multi-Effects Pedal

Compact, Professional-Grade Multi-FX Modeler with Award Winning Line 6 Helix Processing Technology

If you already own a Helix / Helix LT and need something more compact as a pedal-board friendly backup, or thought one of those units was a little out of your price range, then the new Line 6 HX Stomp is here!

A Complete Rig in a Pedal

Perfect for studio recording sessions or life on the road, the conveniently-sized Line 6 HX Stomp  is a complete Guitar or Bass rig in a box. Featuring identical HX Modeling technology as the critically acclaimed Line 6 Helix, along with a 320 x 240-pixel colour LCD, the HX Stomp is a compact multi-effects pedal that will revolutionize your pedalboard rig.

Line 6 HX Stomp Highlights

• Compact, professional-grade Multi-FX modeling unit
• Utilises the same DSP chip and HX Modeling as the award-winning Line 6 Helix
• Highest possible audio quality throughout, plus both true bypass and DSP bypass with trails
• Over 300 effects and models from Helix, M-Series, and legacy Line 6 products
• Up to 6 simultaneous amp, cab, and effect blocks (including a looper and IR loading)
• A complete guitar or bass rig in one pedal
• 3 capacitive-sensing footswitches with color-coded LED rings facilitate ease of use and fast editing
• TRS dual expression pedal/footswitch input extends creative control capabilities
• Stereo effects loop (mono/stereo TRS send + stereo returns) allows use with other pedals

Intuitive Control and Editing

Thanks to both the colour display and the simple but powerful controls, selecting and programming patches couldn't be easier. In addition to this, you also have a measure of external control via MIDI, and there's even an optional Expression Pedal switch for extra flexibility.

Pristine Audio Quality

Featuring an industry-leading 123dB of dynamic range, the Line 6 HX Stomp provides you with a tremendous amount of depth and ultra-low noise signal. Using only the highest-quality components, the HX Stomp guarantees unadulterated audio from start to finish, whether you go direct to the Front of House, or laying down tracks in the studio.

Impressive Effects Library

As with the previous Helix models, the HX Stomp features a huge array of effects, IR simulations, and more. Featuring more than 300 effects and models from the Helix, M-Series, and legacy Line 6 products, and with the ability to simultaneously use up to 6 amp, cab and effect blocks, the HX Stomp is as versatile a modeling unit as you could wish for.

All-New Compact Design

Designed to offer you the best in guitar signal processing, but in a much smaller package than the original Helix, the Line 6 HX Stomp is both powerful and pedalboard friendly. In fact the HX Stomp is so compact that it will even fit into the top pocket of the Helix Backpack, making it perfect for regular gigging or the musician on the go.

What's the Difference Between the Line 6 HX Stomp and the Line 6 HX Effects?

The answer to this question may be more simple than you think (aside from the obvious physical differences).

While the array of HX effects on offer by the HX Stomp is similar to those in the HX Effects pedal (more than 100), the HX Stomp also has access to more than 70 Legacy effects, IN ADDITION to 74 Amp models and 37 Cab sims.

This means that although the HX Effects pedal may be able to run up to 9 presets simultaneously, the HX Stomp has it beat hands down in other areas.

In other words, if you favour the use of Amp and Cab sims alongside your effects, then the Line 6 HX Stomp is the way to go!

Order Yours Today

Contact our online sales team directly to discuss the availability of this fantastic pedal. Alternatively, order your very own Line 6 HX Stomp Online or In-Store today and make use of our fantastic range of home-delivery or in-store pickup services!

Line 6 HX Stomp Highlights

• Compact, professional-grade Multi-FX modeling unit
• Utilises the same DSP chip and HX Modeling as the award-winning Line 6 Helix
• Highest possible audio quality throughout, plus both true bypass and DSP bypass with trails
• Over 300 effects and models from Helix, M-Series, and legacy Line 6 products
• Up to 6 simultaneous amp, cab, and effect blocks (including a looper and IR loading)
• A complete guitar or bass rig in one pedal
• 3 capacitive-sensing footswitches with color-coded LED rings facilitate ease of use and fast editing
• TRS dual expression pedal/footswitch input extends creative control capabilities
• Stereo effects loop (mono/stereo TRS send + stereo returns) allows use with other pedals

Line 6 HX Stomp Technical Specs

Hardware

• DSP Processors: 1 x SHARD ADSP-21469 @ 450 MHz
• A/D/A Converters: 24-bit/192 kHz
• Chassis: Cast aluminium alloy
• Colour LCD: 2.4" diag. 320 x 240-pixel
• Capacitive Touch Footswitches: 3
• Power Supply: External DC (Includes DC-3G)
• Dimensions: 7.01" w x 4.96" d x 2.6" h
• Weight: 1.75lbs

Ins and Outs

• 1/4" Inputs: 4 (Main L/R, Return L/R)
• 1/4" Outputs: 3 (Main L/R, Stereo TRS Send)
• XLR Outputs: 1/4" outs impedance balanced, can use TRS > XLR M cables
• Headphone Output: Yes
• FX Loops: TRS Stereo Send, 2 x Return
• Expression Pedal In: EXP 1/2 (TRS: shared with Footswitch 4/5)
• MIDI In, Out/Thru: Yes
• iPhone/iPad Recording and Playback: Yes
• Input Pad: Yes
• Variable Impedance: Yes Input L (Mono), Right
• 123dB Dynamic Range: Yes Input L (Mono), Right

Presets/Setlists

• Number of Preset Locations: 126 (42 banks x 3 presets)
• Number of Snapshots: 3 per preset

Processing

• Number of Processing Block Locations: Up to 6 (freely assignable, DSP permitting)
• Signal Flow Paths: 1 or 2 Stereo
• Amp Models: 74
• Cabs: 37
• Effects: 200 (123 HX, 77 Legacy)
• User of Third-Party iRs: 128 x 1024 or 2048-point mono
• Simultaneous Impulse Response Blocks: 2 x 1024-point or 1 x 2048-point, DSP permitting
• Input Gate: 1
• Looper Types: 1 Switch Looper
• Looper Memory: 60 Sec Mono, 30 Sec Stereo (Full-Speed)
• Global EQ: Yes
• Dynamic Input Block Routing: Yes

Footswitches

• Number of Footswitches: 3 (+2 via 1/4" TRS jack)
• Change Footswitch Modes with Feet: Via external switch only
• Swap all Stomp Assignments: Yes
• Footswitch Modes: Stomp, Scroll, Preset, Snapshot
• Stomp Footswitch Types: Latching, Momentary
• Maximum Number of Stomp Switches: 5 (3 Internal + 2 External)
• Maximum Number of Preset Switches: 3
• Maximum Number of Snapshot Switches: 3

Controllers

• Number of Controllers: 99 (5 + 94 via MIDI CC)
• Adjust Parameters per Snapshot: 64
• Footswitch as Controller (Toggle Min/Max Values): 8 Per Footswitch

Command Center

• Transmit MIDI Bank/Program Change: Via preset recall only

Other Features

• MacOS/Windows Editor/Librarian/IR Loader Software: HX Edit (2.70 and higher)
• Dedicated Dry USB Out Channels (for Reamping): 4
• Preset List: Yes
• Quick-Reorder Presets: Yes
• MIDI Recall Indicator: Yes
• Repurpose Returns as Stereo AUX In: Yes
• Auto-Assign Wah and Volume Blocks: Mixxion Helix Pedal Only
