Arturia AudioFuse USB Audio Interface - Space Grey

Arturia AudioFuse – a next generation USB audio interface, seen here in a cool Space Grey finish.

AudioFuse USB Audio Interface

Tearing down boundaries, Arturia have have made the AudioFuse USB audio interface compatible with PC, Mac, iOS, Android and Linux.

Fusing professional level audio quality you’d expect from an analogue studio console with the flexibility and portability of a mobile audio interface and wide variety of connectivity options, the AudioFuse has everything you need.

A Focus on Studio Level Sound

When designing the AudioFuse, Arturia were committed to ensuring that professional studio level quality would be at the heart of this audio interface.

Despite being a compact, portable audio interface, the AudioFuse gives you world-class sound, allowing you to take the recording studio with you wherever you go.

High-end components have been carefully selected to ensure the best possible sonic quality including two proprietary DiscretePRO microphone preamplifiers and top-grade AD/DA converters.

Comprehensive and Convenient Connectivity Options

Perfect for the modern musician, recording engineer or producer, the AudioFuse was developed to give the user all the options they could require in any given situation.

Connecting to virtually any audio equipment, the AudioFuse is directly compatible with microphones, instruments turntables, Mac, PC, Linux, tablets, iOS and Android devices and your studio equipment.

In addition to line-level signals, the AudioFuse features two XLR combo-jack inputs on the front allowing you record high impedance instruments such as bass and electric guitar as well as microphones.

¼” TRS jacks and RIAA grounded phono RCA inputs allow you to add two further line level instruments or even a turntable.

To ensure you get the perfect mix, the AudioFuse offers the ability to test across multiple sets of reference monitors and speakers. With two sets of analogue line outputs you can quickly and easily send your mix to different sets of monitoring speakers for comparison.

Two separate headphone outputs in the form of 6.3mm and 3.5mm mean you can easily plug your headphones straight in without the need for an adapter.

In addition to the analogue inputs and outputs, the AudioFuse interface takes full advantage of the digital world.

While USB connectivity allows for easy plug and play use when connecting to a computer, phone or tablet you can also make use of the optical or coaxial S/PDIF I/O to connect with HIFI devices.

Combining the AudioFuse with other ADAT-enabled equipment you can add a further boost to your inputs and output while MIDI connections allow for a whole new dimension of performance and recording possibilities while round-trip latency being as low as 3 milliseconds allows for perfection.

Great Portability

In this day and age, the need to record can strike at any time and the AudioFuse is the tool you need to get it done.

Small enough to carry in one hand, the AudioFuse Advanced Audio Interface can easily be carried anywhere with majority of features being available even when only being powered by USB.

Enabling it to withstand all the rigours of the road, the AudioFuse has a solid aluminium chassis to protect it from damage and dust.

Before shipping out, each unit is individually tested to ensure it meets strict build quality requirements and each one comes with its own test specification printout.

Unrestricted Portable Recording

Built to be taken on the road, equipped with all the connections you could possibly need and the high-end components required for professional studio quality recording, the AudioFuse takes the hurdles away from capturing perfect recordings when you need to.

Providing portable recording without limits so you can record what you want, when you want, where you want, the Arturia AudioFuse advanced audio interface is the complete package.

Arturia AudioFuse Advanced Audio Interface in Space Grey Specs:

Line Inputs

• Input impedance: 20kOhms (symmetric), 10kOhms (asymmetric)
• Maximum input level: +24dBu
• Gain range: from -15dB to 36dB
• Pad mode: -20dB
• Frequency response 20Hz to 20kHz: < +/- 0,08 dB
• Dynamic range: 117dB (A-weighted)
• THD+N: -106dB (A-weighted)

Instrument Input

• Input impedance: 1.1MOhms asymmetric
• Maximum input level: +18dBu
• Gain range: from -15dB to 36dB
• Pad mode: -20dB
• Frequency response 20Hz to 20kHz: < +/- 0,08 dB
• Dynamic range: 117dB (A-weighted)
• THD+N: -104dB (A-weighted)

Line Aux

• Input impedance: 20kOhms (symmetric), 10kOhms (asymmetric)
• Maximum input level: +24dBu
• Pad mode: -20dB
• Frequency response 20Hz to 20kHz: < +/- 0,08 dB
• Dynamic range: 118dB (A-weighted)
• THD+N: -104dB (A-weighted)

Microphone Preamps

• Input impedance: 3.4kOhms
• Maximum input level: +11dBu
• Gain range: from 3dB to 76dB
• Boost mode: +10d; Pad mode: -20dB
• Frequency response 20Hz to 20kHz: < +/- 0,08 dB
• Equivalent Input Noise (EIN): -131.5dBu typical (A-weighted)
• THD+N: -104dB (A-weighted)

Inserts

• Output impedance: 33Ohms
• Input impedance: 10kOhms
• Dynamic range: 119dB (A-weighted)
• Maximum output level: +18dBu
• Maximum Input level: +18dBu
• THD+N: -104dB (A-weighted)

Speakers

• Output impedance: 120Ohms
• Maximum output level: +24dBu
• Dynamic range: 119dB (A-weighted)
• THD+N: -104dB (A-weighted)

Phones

• Output impedance: 33Ohms
• Maximum output level: +10dBu
• Dynamic range: 102dB (A-weighted)
• THD+N: -87dB (A-weighted)
