M-Audio M-Track 2X2 USB Audio Interface
Move your mouse over image or click to enlarge
M-Audio M-Track 2X2 USB Audio Interface M-Audio M-Track 2X2 USB Audio Interface Rear

M-Audio M-Track 2X2 USB Audio Interface

by M-Audio
The M-Audio M-Track 2X2 USB audio interface from M-AUDIO is very easy to use and allows you to produce some great, studio-quality recordings..

Read More



The M-Audio M-Track 2X2 USB audio interface from M-AUDIO is very easy to use and allows you to produce some great, studio-quality recordings.

USB Audio Interface – Zero Latency Recording

Studio Quality Recording

Using the M-Track 2X2 you can create incredible 24-bit/192kHz studio-quality recordings and manage it all from the easy to use on-board interface. One great feature of the M-TRACK 2X2 is that you’re able to record two channels at once. On the first channel is an XLR + ¼” combo input with switchable phantom power so you can use any microphone.

The second channel has a ¼” instrument input with a specially designed gain and impedance stage so you can get the most accurate representation of your instrument when you plug it directly into the M-Track.

M-AUDIO M-TRACK 2X2 Key Features:

  • 24/-bit/192kHz Resolution for Professional Quality Recording
  • Crystal Preamps and Pristine D/A Converters for Clear, Dynamic Capture
  • Elegant Pro-Grade Metal Chassis
  • Future-Proofed High-Speed, Zero Latency Recording
  • USB Powered
  • Dedicated XLR+1/4” Combo Input for Mic/Line Sources
  • Dedicated ¼” Instrument Input for Guitar or Bass
  • Stereo ¼” Main Outputs and 12/4” Headphone Output
  • Great Software Package: Cubase LE, C-Series VI suite, Pro Tools First
  • Includes 2GB (500+ sample) cutting-edge sound library from leading content developer Touch Loops.

Simple to Use

Install the drivers, easily connect the M-Track 2X2 to your PC or Mac via a standard USB or USB-C port with one of the two cables that are included and you’re ready to record. The software you need to record is all included so you can just get straight to work.

With this high-speed USB connection working with the USB/Direct balance knob you can monitor and record the with zero latency, making for an extremely easy recording process.

Ultra-Portable with Professional Quality

Coming in a very elegant, slim-line metal chassis, the M-TRACK 2X2 is easily taken with you to wherever you need to record. Being USB-Bus powered you don’t even have to worry about how you’re going to power it – when you connect it to your PC/Mac or Laptop it gets all the power it needs via USB.

For incredible quality in such a compact, portable device, M-AUDIO have equipped the M-TRACK 2X2 with all-new professional level Crystal Preamps and pristine D/A converters providing 24-bit resolution for awesome dynamic range able to capture all the subtleties, expression and nuances of your performance.

With sample rates up to 192kHz you can be confident that your recordings are crystal clear and completely faithful to your source.

Included Software

Another great thing about the M-TRACK 2X2 USB audio interface is that it comes with all the software you need to get started recording your performances and all the included software is compatible with both Windows and OSX.

  • Cubase LE

Using Cubase LE your computer becomes your personal recording studio. It’s a very straight forward DAW (Digital Audio Workstation) giving you the basic tools needed for recording, editing and mixing. You can use Cubase LE to throughout the whole process; from getting down rough ideas to mixing your finalised recordings.

  • C-Series VI Suite

The C-Series VI Suite includes Strike, Xpand!2 and Mini-Grand among many, many other critically acclaimed sounds that have been meticulously designed by professional sound designers. From synth-scapes to realistic drum tracks or realistic sounding grand piano – this suite of virtual instruments is everything you need to produce a full sound and unleash your creativity unhindered.

  • Creative FX Collection

Included with Pro Tools since Version 8, the AIR Creative FX collection features 20 plug-ins to help you get the most out of your recordings. It contains everything you need for producing, mixing and mastering your audio and includes great features such as reverbs, compressors, delays, filters and EQ.

NEW Includes 2GB Sound Library of In-Demand Sound Content From Touch Loops

Spark that initial idea or add the finishing touch to your latest masterpiece – whatever your production needs, Touch Loops’ 2GB sample library doesn’t disappoint! Based in Los Angeles and London, Touch Loops equips customers with the most cutting-edge sound elements, instruments, hardware, and software recordings, expertly curated by a team of professional music producers and sound designers. Now included with M-Track 2x2, this 500+ sound library provides everything from must-have one shot drum hits to sultry melodic loops and deep, driving bass - whatever your project demands, this expertly curated sample content arms you with cutting-edge content to realise it!

NEW Includes Pro Tools First

First isn’t a stripped-down application. It's based on the same music creation and audio production tools that award-winning artists, musicians, producers, engineers, and mixers rely on every day. All built on the rock-solid, great-sounding Pro Tools audio engine. Over 70% of all commercial music is produced using Pro Tools.

Pro Tools | First opens the door to a career in professional music production. Start learning the essential workflows required to succeed in the industry.


  • Mic Input 1 (balanced XLR)
  • Frequency Response: 20 Hz - 20 kHz (+0.1 dB)
  • Dynamic Range: 104 dB (A-weighted)
  • Signal-to-Noise Ratio: 104 dB (+1.0 dBu, A-weighted)
  • THD+N: 0.003%
  • Preamp EIN: -128 dBu (max gain, 150  source, A-weighted)
  • Max Input Level: +1.5 dBu
  • Gain Range: 55 dB
  • Line Input 1 (balanced 1/4" [6.35 mm] TRS)
  • Frequency Response: 20 Hz - 20 kHz (+0.05 dB)
  • Signal-to-Noise Ratio: 101 dB (1 kHz, +4 dBu, A-weighted)
  • THD+N: 0.003%
  • Max Input Level: 16 dBu
  • Gain Range: 55 dB
  • Inst Input 2 (unbalanced 1/4" [6.35 mm] TS)
  • Frequency Response: 20 Hz - 20 kHz (+0.05 dB)
  • Dynamic Range: 100 dB (A-weighted)
  • Signal-to-Noise Ratio: 102 dB (+ 4 dBu, A-weighted)
  • THD+N: 0.004%
  • Max Input Level: 6 dBu
  • Input Impedance: 1 M
  • Gain Range: 24 dB
  • Main Outputs, L and R (impedance-balanced 1/4" [6.35 mm] TRS)
  • Frequency Response: 20 Hz - 20 kHz (+0.06 dB)
  • Dynamic Range / Signal-to-Noise Ratio: 102 dB (A-weighted)
  • THD+N: 0.005%
  • Max Output Level: +7 dBu (1 kHz, -1 dBFS)
  • Headphone Output (1/4" [6.35 mm] TRS)
  • THD+N: 0.005%
  • Output Impedance: 10

Minimum System Requirements:

  • Standard USB 2.0 or USB-C Port
  • Windows: 7 (32 or 64 bit) OSX: 10.8


Weight (kg)1.0000
Power Supplyusb-bus-powered
USB ConnectionYes
Phantom PowerYes
Channels2 channels
