AER Compact 60 Mk4 Acoustic Amp Brown Textured Finish
Move your mouse over image or click to enlarge

AER Compact 60 Mk4 Acoustic Amp Brown Textured Finish

by AER
The AER Compact 60 MK4 returns with a great looking brown textured finish while boasting the same exceptional sound and convenient features ..

Read More

£890.00

Overview

The AER Compact 60 MK4 returns with a great looking brown textured finish while boasting the same exceptional sound and convenient features you expect from this great amp.

Perfect Amp for Singer-Songwriters

The AER Compact 60 is known as one of the best acoustic guitar amps on the market.

Now in its fourth iteration, the AER Compact 60 boasts its best performance yet.

This particular model comes with a new brown textured finish, giving it a warm and natural aesthetic to complement your acoustic set up.

Plus, while it’s designed for amplifying acoustic instruments and enhancing their sound, you will also get great results when using the AER Compact 60 to amplify electric instruments too.

AER Compact 60 Mk4 Acoustic Amp Brown Textured Key Features:

  • Suitable for both Acoustic and Electric Instruments
  • Two Channels, Both with Dedicated EQ
  • A Wide Range of Convenient Controls
  • DI Out and Effects Loop
  • Auxiliary Input
  • Headphone Output
  • 48 V Phantom Power for Condenser Microphones
  • 9 V Phantom Power for Instrument Preamps
  • Includes Gig Bag

Two Channels with Individual Tone Shaping

Giving you an all-in-one live performance solution, the AER Compact 60 Mk4 features two separate channels.

Channel 1 takes is designed for instruments and features a jack input for connecting whatever you have such as electro-acoustic guitar.

Channel 2 is equipped with an XLR/jack combo input so you can connect either a microphone or even a second instrument. Using the mic/line switch you can easily set channel 2 up for your chosen source.

Furthermore, so you can get the perfect sound, each channel has its own independent EQ.

Convenient Features

If you need to power your instrument’s preamp, on the back of the AER Compact 60 you can activate 9v phantom power for Channel 1.

You also have the option for activating 48v phantom power on Channel for use with condenser microphones.

A headphone output allows you to practice privately, switching off the internal speaker when in use.

Plus, there’s a 3.5mm jack aux input allowing you to connect line level sources such as your phone or mp3 player.

Great for Effects

The AER Compact 60 IV boasts a few high-quality built-in effects to really add dimension and atmosphere to your sound.

With tis digital effects processor, the AER Compact 60 gives you access to two separate reverb effects, delay and chorus. Classic acoustic guitar effects.

If you want to, you can easily add in external effects with the Send and Return connections while the DI-out with a balanced XLR output can be switched to be with or without effects.

Furthermore, the AER Compact 60 features a footswitch input so you can connect a footswitch for dual switching, toggling on/off either internal or external effects.

Great for Gigging

AER have designed the Compact 60 acoustic amplifier with gigging in mind and as such it is very lightweight and portable.

It even comes with a gig bag so it’s even easier to carry around and get your stage set sorted quickly.

Buy the AER Compact 60 Mk4 Acoustic Amplifier from PMT Online today for a fully featured and highly portable live sound solution.

AER Compact 60 Mk4 Acoustic Amp Brown Textured Specs:

Inputs

Channel 1

  • Instrument / line input, high impedance, unbalanced
  • Stereo jack socket*: ¼“ (6.35 mm)
  • Nom. input voltage: 100 mV (–20 dBV)
  • High/low (attenuator) switch: –10 dB
  • Min. input voltage:
  • high: 22 mV (–33 dBV)
  • low: 68 mV (–23 dBV)
  • Max. input voltage (THD = 1%):
  • high: 3.5 V (+11 dBV)
  • low: 5 V (+14 dBV)
  • Input impedance: 2.2 MoHMS || 350 pF
  • Signal / noise ratio (A-weighted): 95 dB
  • Equivalent input noise voltage
  • (A-weighted): 1.8 V (–115 dBV)
  • Phantom power (switchable): 9 V DC
  • Load current: max. 100 mA
  • Short circuit protected.

*Ring used for phantom power.
Clip indicator headroom: approx.. 6 dB

Channel 2

  • Switchable input with line and microph. mode
  • Combo socket: XLR + jack ¼” (6.35 mm)

line mode (jack input only)

  • Instrument / line input, high impedance, unbalanced
  • Nom. input voltage: 100 mV (–20 dBV)
  • Min. input voltage: 27 mV (–31 dBV)
  • Max. input voltage: 7 V (+17 dBV)
  • Input impedance: 2.2 MOHMS || 350 pF
  • Signal / noise ratio (A-weighted): 92 dB
  • Equivalent input noise voltage
  • (A-weighted): 2.7 V (– 111 dBV)

mic mode

  • Microphone input, XLR (balanced), stereo jack
  • (balanced), mono jack (unbalanced)
  • 1 / sleeve = ground,
  • 2 / tip = positive (+),
  • 3 / ring = negative (–)
  • Nom. input voltage: 10 mV (–40 dBV)
  • Min. input voltage: 3.3 mV (–50 dBV)
  • with option: 5.8 mV (–45 dBV)
  • Max. input voltage: 1 V (0 dBV)
  • with option: 1.6 V (+4 dBV)
  • Input impedance (balanced): 1.2 kOhms
  • Input impedance (unbalanced): 2.7 kOhms
  • Voice filter (referred to 10 kHz):
  • –10 dB at 270 Hz
  • Signal / noise ratio (A-weighted): 80 dB
  • Equivalent input noise voltage
  • (A-weighted): 1 V (–120 dBV)
  • Phantom power (XLR only): 48 V
  • Supply resistors: 6.8 koHMS
  • Load current: max. 10 mA
  • Clip indicator headroom: approx. 6dB

Return

  • Input for external parallel effect loop (send / return), or supplementary input
  • Mono jack socket: ¼” (6.35 mm)
  • Nom. input voltage: 320 mV (–10 dBV)
  • Max. input voltage: 5 V (+14 dBV)
  • Input impedance: 20 kOhms

Auxiliary input, e.g. for CD

  • Stereo jack socket: 3.5 mm
  • Nom. input voltage: 500 mV (–6 dBV)
  • Min. input voltage,
  • stereo: 100 mV (–20 dBV)
  • mono: 200 mV (–14 dBV)
  • Max. input voltage: 4 V (+12 dBV)
  • Input impedance: 22 kOhms

Output

Line Out

  • Preamplifier output post master, tone controls, and effects
  • Mono jack socket: ¼” (6.35 mm)
  • Nom. output voltage: 700 mV (–3 dBV)
  • Output impedance: 100 Ohms
  • Min. load impedance: 2 kOhms
  • Residual noise (A-weighted): 4.5 V (–107 dBV)

Headphones

  • Headphones output
  • Stereo jack socket: ¼” (6.35 mm)
  • Output power (THD < 1 %):
  • 8 Ohms 2 x 2 mW
  • 32 Ohms 2 x 7 mW
  • 2000 Ohms 2 x 50 mW
  • Output impedance (per channel): 1000 Ohms
  • Residual noise (A-weighted), referred to rated
  • output power: –94 dB
  • When plugged in, the internal speaker is switched off.

Send

  • Output pre master, post tone controls, for external parallel effect loop (send / return)
  • Mono jack socket: ¼” (6.35 mm)
  • Nom. output voltage
  • (pan cantered): 300 mV (–10 dBV)
  • Output impedance: 47 Ohms
  • Min. load impedance: 2 kOhms

Tuner

  • Tuner output, post tone controls, pre effects and master
  • Mono jack socket: ¼” (6.35 mm)
  • Nom. output voltage: 100 mV (–20 dBV)
  • Output impedance: 47 Ohms
  • Min. load impedance: 2 kOhms

DI-Out

  • Balanced, non-isolated XLR output, post tone controls, switchable pre or post effects
  • 1 = ground,
  • 2 = positive (+),
  • 3 = negative (–)
  • Nom. output voltage (differential):
  • 41 mV (–28 dBV)
  • Output impedance (per terminal): 47 Ohms
  • Min. load impedance (differential): 1 kOhms

Footswitch Connector

  • Connector for a dual footswitch
  • (dual, latching, toggle on-off switch)
  • Stereo jack socket: ¼” (6.35 mm)
  • Tip = internal effect on/off
  • Ring = external effect on/off
  • Sleeve = common (ground)
  • Function: Switch ON = effect OFF

Tone Controls

Channel 1

  • colour at 700 Hz –3 dB
  • at 8 kHz +10 dB
  • bass at 100 Hz (shelf type) ±10 dB
  • middle at 800 Hz ±6 dB
  • treble at 10 kHz (shelf type) ±8 dB

Channel 2

  • bass at 100 Hz (shelf type) ±8 dB
  • treble at 10 kHz (shelf type) ±11 dB

Internal Effects

  • Digital effect processor
  • 1 Reverb
  • 2 Reverb with longer predelay
  • 3 Delay (320 ms, repetitive)
  • 4 Chorus

AER Compact 60 Mk4 Acoustic Amp Dimensions and Weight:

Dimensions

  • Height: 260mm (10.20”)
  • Width: 325mm (12.8”)
  • Depth: 235mm (9.25”)

Weight

  • 7.1kg (15.6lbs)

Specification

SKU182394
Weight (kg)8.0000
MPNCOMPACT60BTF
Power60 watts
Amp Typeacoustic guitar amplifier
